46. JNB bit address, code address (Jump if bit is not set)
00110000
70
Instruction code
Bit address
Relative offset
Operations
Number of bytes
Number of cycles
Flags
(PSW)
Description
: Byte 1
R7 R6 R5 R4 R3 R2 R1 R0
70
Byte 3
(PC)←(PC)+3
IF (bit address)=0
THEN
(PC)←(PC)+relative offset
:
C AC F0 RS1 RS0 OV F1 P
:
:
:
Control is shifted to a relative jump address if the specified bit
address content is 0, but shifted to the next address following
this instruction if the content is 1.
:
3
2
b7 b6 b5 b4 b3 b2 b1 b0
70
Byte 2
