SAFETY PRECAUTIONS
13. Safety Devices and Functions
14. Symbols Used in This Manual
The following warning indications are used in this manual to draw attention to information of particu-
lar importance. Read the instructions marked with these symbols carefully and follow them.
Contents Location Remark
Front shield with safety glass and polycarbonate Machine optional
Shield open/close interlock Machine
Chuck interlock Electric control cabinet optional
Software limit Operation panel
Chuck barrier Operation panel
Turret barrier Operation panel
Emergency stop button Operation panel
Slide hold button Operation panel
Alarm display Operation panel
Short circuit breaker Electric control cabinet optional
Cycle start requiring simultaneous depression of both buttons Machine optional
Magazine door open/close interlock Machine
indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
indicates a potentially hazardous situation which, if not avoided, may result in minor or moder-
ate injury.
indicates a potentially hazardous situation which, if not avoided, may result in damage to your
property.
indicates general instructions for safe operation.
DANGER
WARNING
CAUTION
CAUTION
SAFETY INSTRUCTIONS
