Okuma VTM-200 - Section 5 Spare Parts List; Air Equipment

5699-E P-70
SECTION 5 SPARE PARTS LIST
SECTION 5 SPARE PARTS LIST
1. Air Equipment
*1: for ABSO scale spec only
*2: for ATS spec only
*3: for automatic door spec only
No. Part Name Maker Type Qty. Used for Okuma Part No.
1 FR unit CKD
C3020-10-FL332155
1 Air panel
H0140-0017-38
(for Japan)
C3020-10-FL332154
H0140-0017-39
(for overseas)
(Filter) (CKD) (F3000-10-F) (1) (Air panel) (H0032-0006-48)
(Regulator) (CKD) (R3000-10-T8) (1) (Air panel) (F0015-510-000-68)
Pressure gauge (CKD)
(G41D-8-P10)
(1) (Air panel)
(T019-400-007-25)
(for Japan)
(G41D-8-PS15)
(T019-400-006-42)
(for overseas)
2 Filter set CKD
C4000-10-FL417412
1 (*1) Air panel
H0140-0024-08
(for Japan)
C4000-10-FL417382
H0140-0024-14
(for overseas)
Drain separator (CKD) (FX1004-10-FX1) (1) (Air panel*) (H0032-0017-67)
Oil mist filter (CKD) (M4000-10-FL300077) (1) (Air panel*) (H0032-0014-30)
Oil mist filter (CKD) (MX3000-10-F1X1) (1) (Air panel*) (H0032-0017-66)
Pressure switch (CKD) (P4100-10-3) (1) (Air panel*) (E3040-453-060)
Regulator (CKD) (R3000-10-LT8X1) (1) (Air panel*) (F0015-410-002-24)
Pressure gauge (CKD)
(G41D-8-P02)
(1) (Air panel*)
(T019-400-007-44)
(for Japan)
(G41D-8-PS03)
(T019-400-006-38)
(for overseas)
3 S solenoid valve CKD GAB412-5-3-2H-DC24V 1 M-spindle headstock F0001-400-002-66
(S solenoid valve) (CKD) (GAB412-5-0-02HS-DC24V) (3) (M-spindle headstock) (F0001-400-005-80)
4 Regulator SMC AR20-02BG 1 M-spindle headstock F0015-410-001-43
5 Gap sensor ASAHI 616JX2-LDC-N 1 M-spindle headstock T019-400-010-10
6 Speed controller SMC AS3211F-03-06S 2 M-spindle headstock F0031-582-000-51
7 In-line check valve Japan Controls 2232B-3SS 1 M-spindle headstock F0040-582-000-04
8 D solenoid valve CKD M4GA380-C8-B-5-3 1 ATC shutter F0000-452-001-62
(D solenoid valve) (CKD) 4GA339-C8-B-3 (1) (ATC shutter) (F0000-452-001-63)
(Speed control valve) (CKD) SCL2-08-H88 (2) (ATC shutter) (F0031-281-000-01)
(Silencer) (CKD) SLW-10A (2) (ATC shutter) (H0036-0001-65)
(Single operation joint) (CKD) GWS10-10 (1) (ATC shutter) (H0016-0000-74)
9 Air cylinder SMC CM2L-32-750A 1 ATC shutter H0002-0019-05
10 D solenoid valve CKD 4GA349-C8-B-3 2 (*2) ATS F0000-453-000-64
11 Speed control valve SMC AS2201F-01-06S 2 (*2) ATS H0016-0013-15
12 Air cylinder CKD CMK2-00-32-495 1 (*2) ATS H0002-0030-98
13 Speed control valve SMC AS1201F-M5-06S 2 (*2) ATS H0016-0008-58
14 Air cylinder CKD SCM-Q-00-25B-200-R-Q 1 (*2) ATS H0002-0030-99
15 S solenoid valve CKD FAB41-8-5-12HSB-3 1 (*2) ATS F0001-400-003-93
16 D solenoid valve CKD 4GA399-C8-B-3 1 (*3) Swing door F0000-452-001-63
17 Air cylinder SMC CDQ2B20-45DM-F7BVSDPC 1 (*3) Swing door H0002-0031-11
18 D solenoid valve CKD 4GA349-C10-B-3 1 (*3) Automatic door F0000-453-000-65
19 Speed control valve SMC AS3301F-03-10 2 (*3) Automatic door F0031-582-000-59
20 Air cylinder SMC SCA2-G-LB-50B-1700 1 (*3) Automatic door H0002-0030-67
