SECTION 3 OPERATION (OF CNC LATHE)
2. Machine Operation
2-1. Axis Direction
LE11214R0100500100001
Axis movements and directions:
Travel Positive direction
X-axis Lateral movement perpendicular to the headstock To the right
Z-axis Vertical movement along the headstock Upward
C-axis Chuck rotation CCW rotation
