SECTION 4 INSPECTION, MAINTENANCE AND ADJUSTMENTS
2-1. Lubrication Chart Symbols
Description Symbol Comments
Oil Level
Replenish
Change
Pressure Gauge
Thermometer
Oil Filter
• Clean or Change filter element.
• Check condition of filter element.
Flow Sight
Check oil flow by visual inspection
through window, gear, rotary ring or
spout devices.
Oil Pump
Operate manual pump with lever or
button.
Separator
Clean the magnetic coolant separa-
tor.
Time
(Operating hours)
Inspection
This symbol is used in combination
with other symbols.
To Next Page
