HVBTR1600USERMANUAL
HVBTR1600_User_Manual_V1
HVBTR1600PVRREADYSETTOPBOX

FrontPanel


,WHP 'HVFULSWLRQ

STANDBY

USB

CH+/- VOL+/-

RearPanel




Item Description Item Description
1 AntennaINsocket6HDMIOutput
2 RFLoopOutSocket.7SVIDEO
3 Y/PB/PRVideoOutput8SPDIF:CoaxialDigitalAudioOut
4 AudioLeft/Rightoutput9MainON/OFFSwitch
5 CBVSCompositeVideoOut10 ACPowerCord



-5-
