Index Part's Number Description Specification QTY
2.1 051037-902 Faceplate 2
2.2 001903-105 Set Screw M8*1.25P*8 2
2.3 360956-902 Collar M35*1.5P 1
2.4 030202-002 Ball Bearing 6007 1
2.5 006714-100 Wave Washer WW6305(47.2*60.2) 1
2.6 360957-902 Bushing 1
2.7 010014-000 S-Ring STW-35 1
2.8 300089-000 Pulley 1
2.9 001901-101 Set Screw M5*0.8P*5 6
2.10 380951-902 Bushing 3
2.11 660120-000 Sensor Ring 1
2.12 361127-000 Spindle 1
2.13 012006-001 Key 8*8*40 1
2.14 001902-105 Set Screw M6*1.0P*12 6
3 380950-902 Knock Out Bar 1
9 051257-000 Headstock 1
15 030223-002 Ball Bearing 6208 1
18 922506-000 Spur Center Assembly 1
18.1 380952-901 Spur Center 1
18.2 380443-906 Tip 1
19 000804-104 Round Head Screw M5*0.8P*6 1
22 173742-904 Cover 1
23 000805-101 Round Head Screw M4*0.7P*6 2
24
014344-000 V-Belt
540J-8 1
25 000105-105 Cap Screw M10*1.5P*40 4
26 006307-100 Spring Washer 10.2*18.5 12
27 006001-069 Flat Washer 10*20*3t 12
28 921915-000 Knurled Screw Assembly 1
29 001602-701
Pan Head Screw w/Flat Washer 1
30 660002-000 Pan Head Screw M5*0.8P*10/5*12*0.8t 2
31 008302-100 Set Screw M5*0.8P/(8B*6H) 2
32 006001-012 Flat Washer 5.3*12*1.0t 6
33 230316-902 Long Hinge 1
34 003301-203 Pan Head Screw 1/4"-20NC*5/8" 1
35 172660-164 Guard 1
36 230156-615 Knob 1
37 000804-107 Hex Socket Screw M5*0.8P*12 12
38 361124-901 Shaft 1
39 000303-103 Pan Head Screw M5*0.8P*10/5*12*0.8t 1
40 923683-000 Digital Display Switch Box Assembly 1
40.1 830004-001 Safety Switch 1
40.2 240057-000 Knob
1
40.3
572468-000 Switch Box Plate 1
40.4 250783-615 Digital Display Switch Box 1
40.5 490884-000 Digital Display 1
2018 Parts List
