Oliver 2018 User Manual

Index Part's Number Description Specification QTY
26 006307-100 Spring Washer 10.2*18.5 12
27 006001-069 Flat Washer 10*20*3t 12
37 000804-107 Hex Socket Screw M5*0.8P*12 12
62 000105-107 Cap Screw M10*1.5P*50 8
63 000101-701 Cap Screw M4*0.7P*8 1
64 021103-000 Wire Clip ACC-3 1
65 173743-904 Bed Cover 1
66 000305-102 Pan Head Screw M8*1.25P*12 2
67 051031-000 Bed 1
68 950623-000 Button Switch Assembly 1
68.1 490883-000 Forward/Reverse Switch 1
68.2 573959-000 Button Switch Label 1
68.3 250982-615 Switch Box 1
68.4 000303-104 Pan Head Screw M5*0.8P*12 2
68.5 006001-012 Flat Washer 5.3*12*1.0t 2
68.6 008004-100 Hex Nut M5*0.8P(8B*4H) 2
68.7 473001-020 Power Cord SJT18AWG*3C*650mm 1
68.8 021601-000 Wire Proector 1/2" 2
70 000006-102 Hex Screw M16*2.0P*60 4
71 008011-100 Hex Nut M16*2.0P(24B*13H) 5
72 173740-902 Foot 4
89 051033-000 Stand, Right 1
2018 Parts List
LATHE BED
