Index Part's Number Description Specification QTY
1 001902-109 Set Screw M6*1.0P*6 2
12 001901-101 Set Screw M5*0.8P*5 1
41 360918-907 Banjo Lock Rod 1
42 010035-000 S-Ring STW-22 2
43 380953-902 Bushing 1
44 051036-000 Banjo 1
45 070052-902 Tool Rest 1
46 921423-000 Lock Handle Assembly 3/8"-16UNC-1"L 1
47 380946-902 Adjust Rod 2
48 380504-901 Lock Washer 2
49 009101-200 Lock Nut 3/4"-10NC*17mm 2
50 922456-000 Live Center Assembly 1
50.1 380415-901 Top Point 1
50.2 380413-901 Cap 1
50.3 030112-002 Ball Bearing 6002 1
50.4 380414-901 Taper Shank 1
51 360923-000 Tailstock Scale Sleeve 1
52 921456-000 Lock Screw Assembly 5/16"-18UNC-20L 1
53 051035-000 Tailstock 1
54 380510-901 Tailstock Screw 1
55 240072-000 Handwheel 1
56 230114-906 Handle 1
57 011003-110 Spring Pin 5*40 1
58 000103-707 Cap Screw M6*1.0P*20 1
59 130190-000 Socket 1
60 010030-000 S-Ring STW-19 2
61 360920-907 Lock Handle 1
2018 Parts List
