3-10 d-COLOR MF3100
Installing optional units
3
3.3
4 The printer must be held by two people. Correctly set the Lower Feeder Unit by aligning the positioning
pins with the pin receiving holes at the bottom of the printer.
NOTICE
This printer weighs approximately 75-5/8 lb (34.3 kg), including consumables. Two people are always
required to lift the printer.
5 Close the Right Door of the Lower Feeder Unit.
6 Connect the interface cable.
To Next Page
