17Technical description
Cable control
The hand controller is normally used in radio mode
but it is also possible to operate it via a cable.
A four-metre cable (E0781) is supplied as standard
with the hand controller. The cable is intended to be
used for short-term operation and when pairing in
conjunction with the replacement of hand controllers
or decoders. The cable connects to the vehicle via
the decoder’s CAN bus connector. (3)
If the hand controller is to be wired permanently or
for a long period, an adapter cable (E0837) is run
from the Space X4 RC system and installed at a
suitable location on the vehicle. To give the opera-
tor greater freedom of movement, a 15-metre cable
(E0782) is used between the adapter and the con-
troller. (4)
When the cable is connected to the hand controller,
the centre display shows that the controller is in ca-
ble operation mode. The symbols for signal strength
(radio) and battery capacity are replaced with the
symbol for cable operation. (5)
Engage manual extension
This function must be activated so that the safety
system can calculate the capacity when manual ex-
tension is used. This is done by pressing the release
and horn buttons at the same time until the manual
extension symbol appears on the centre display.
Use the same procedure to disengage the manual
extension function.
3
4
5
