Menu system
8
Olsbergs hand controllers are equipped with a
menu selection system as standard.
There are three main menus which can be easily
accessed via three push buttons.
The main menus are:
the CRANE menu
the EXTRA menu
the ON-OFF menu
In each of the main menus the operator can select
sub-menus by repeatedly pressing the same button,
e.g. 1-2-3 and then back to 1 again.
The sum of Crane and Extra menus may not ex-
ceed 4. For a 6-lever hand controller, the maximum
number of On-Off menus are 3 with on/off functions
on lever 2,3,4 and 5.
The system with main menus enables the operator
to change quickly from crane operation to outrig-
ger operation and back again. The hand controller
always restarts in menu CRANE 1.
ON-OFF
menu
1,2,3
EXTRA
menu
2,3,4
CRANE
menu
1,2,3,4
Crane Extra On-Off
1
2 3 4 5 6
Technical description
