Chapter 3 Preparation and Inspection
43
ULTRASONIC BRONCHOFIBERVIDEOSCOPE BF-UC180F
4. Turn the lever counterclockwise until it stops (see Figure 3.22).
Figure 3.22
5. Press the lever down until it snaps into place, securing the ultrasonic
connector to the system (see Figure 3.23).
Figure 3.23
6. Close the flip cover of the compact endoscopic ultrasound center.
