Olympus BX51 - Page 9

BX51
5
Transmitted/reflected light
switch
Transmitted light/reflected light specification model
BX51TRF microscope frame
NOTE
* For the reflected illuminators and reflected lamp housings, please also refer to their instruction manuals.
The controls are identical to those of the transmitted light specification models except for the transmitted/
reflected light switch and the reflected light system (vertical illuminator, reflected lamp housing).
Reflected light illuminator*
· Universal illuminator
(BX-URA2)
· Fluorescence illuminator
(BX-RFA)
· Vertical illuminator
(BX-RLA2)
Reflected lamp housing*
· 100 W mercury burner housing
(U-LH100HG)
· 100 W mercury apo-burner housing
(U-LH100HGAPO)
· 75 W xenon lamp housing
(U-LH75XEAPO)
· 100 W halogen lamp housing
(U-LH100-3)
· System lamp housing
(U-ULH, halogen bulb specification)
(for exclusive use with
the halogen light source)
