23
SPECIFICATIONS
Item Specification
Optical system UIS2 (UIS) (Universal Infinity System) optical system
Reflected light illumination Reflected light illuminator (BX-RLA2), tube magnification 1X, super widefield (FN 26.5) compat-
ible.
Available observations: @Reflected light brightfield
²Reflected light darkfield
³Reflected light Nomarski DIC
|Reflected light simplified polarized light
Electrical system Rated input voltage: 100-120 V/220-240 V , 1.8 A/0.8 A, 50/60 Hz.
Light intensity voltage range: 1.0 to 12.0 V DC (continuously variable)
12 V, 100 W long-life halogen bulb (pre-centered) 12V100WHAL-L (PHILIPS 7724)
12 V, 50 W long-life halogen bulb (pre-centered) 12V50WHAL-L (LIFE JC)
Average life time: Approximately 2000 hr. when used as directed.
Light preset switch: Preset voltage can be set arbitrarily between 1.0 and 12 V.
Power consumption: 140 W
Focusing system Stage height movement by roller guide (rack & pinion)
Stroke per rotation: 0.1 mm (fine), 17.8 mm (coarse)
Full stroke range: 25 mm
Upper limit stopper
Tension adjustment on coarse focus adjustment knob.
Revolving nosepiece U-5RE-2
DIC slider insertion type:
U-D6RE, U-D7RE, U-D5BDRE, U-D6BDRE, etc.
Observation tube
U-BI30-2
Widefield
binocular
U-TR30-2
Widefield
trinocular
U-ETR3
Widefield
erected
trinocular
U-ETBI
Widefield
erected tilting
binocular
U-SWTR-3
Super
widefield
trinocular
U-SWETR
Super
widefield
erected
trinocular
U-SWETTR2
Super
widefield
erected tilting
trinocular
FN 22 FN 26.5
Tube tilting angle: Fixed
Tilting angle
25°
Tube tilting angle: Fixed
Tilting angle
35°
Interpupillary distance adjustment: 50 to 76 mm
Stage U-SIC4R2/SIC4L2
Coaxial knobs on bottom right (left).
4 x 4 inch stage
U-SVRM/USVLM
Stage with coaxial knobs on the bottom right (left)
Drive system: Rack & pinion drive
Stroke: 100 Y-axis x 105 X-axis mm
Y-axis lock: Fixing in Y-axis direction
using a lock lever
Drive system: Wire drive
Stroke 52 Y-axis x 76 X-axis mm
X/Y-axis knob rotation tension adjustment available
Operating environment · Indoor use.
· Altitude: Max. 2000 meters
· Ambient temperature: 5° to 40°C (41° to 104° F)
· Maximum relative humidity: 80% for temperatures up to 31°C (88°F), decreasing linearly
through 70% at 34°C (93°F), 60% at 37°C (99°F), to 50% relative humidity at 40°C (104°F).
· Supply voltage fluctuations: ±10%
· Pollution degree: 2 (in accordance with IEC60664)
· Installation (overvoltage) category: II (in accordance with IEC60664)
