Connecting
the
Power
Cord
(R9.
1.
Make
sure
that
the
main
switch
(?)
a
on
OFF.
2.
Before
shipment
from
the
factory,
the
voltage
selector
switch
fj)
u
set
to the
200-240V
position.
In
C33e
your
local
line
vortaga
is
10O-120V,
move
the
switch
to
tha
100-120V
position
using
a
flat-head
screwdriver.
3.
Insen
the
power
cord
into
the
AC
receptacle
®
on
the
frame.
4.
Connect
tha
power
cord's
ground
wire
to
the
ground
terminal
on
the
wall
outlet
then
plug
the
power
cord
into
the
wall
outlet,
(in
case
of
a
three-prong
power
cord
and
wall
outlet separate
grounding
is
not
necessary.)
Fuse
Replacement
(Fig*.
20, 21)
O
Before
replacing
fuses,
set
tha
main
switch
to
OFF
and
unplug
the
power
cord,
(the
power
cord should
be
unptugged from
the
AC
recepocle
to
allow
removal
of
the
fuse
holder.)
1.
Remove
the
fuse
holder
(t)
by
squeezing
it
at
both
sides
and
puling
outward.
fFtg.
20)
2.
Replace
both
fuse3
©
with
new
ones.
{Fig.
21)
*
Use
only
specified
fuses.
Applicable
fuse:
260V,
SA
slow-blow
(Tims
Lag)
High-Breaking-Capacity,
2
fuses
(UTTLEFUSE
215005)
tnu
Dm
ad.
