BX60
7. Looking through the right eyepcece with your light eye. turn the coarse adjustment
knob to bring the specimen into focus. After obtaining approximate focus, use
the fine adjustment knob to make final focus adjustments. (Page 25)
B. Looking through the left eyepiece with your left eye, turn the diopter adjustment
ring to focus on the specimen. (Page 25)
9. Confirm that the illumination is adequate for the observation purpose.
IPage 32)
10. Engage the required filter.
11. Engage the objective to be used for observation, then readjust the focus and
adjust the light intensity to a suitable level for observation.
12. In case of reflected light brightfteU observation, select the best field and
aperture iris diaphragm settings in accordance with the objective and specimen.
(Pages 20. 21)
1
16
