Specifications - DP28
Chip type C-mount CMOS camera
Chip size 1 Inch
Recording area
14.158 mm x 7.5 mm
16.02 mm diagonal
Maximum resolution
4104 x 2174 pixels
8.92 million pixels
Camera port of the microscope C-Mount
Input / output
On the camera:USB 3.1 type C (with
lock screws)
On the computer or DP2-AOU : USB
3.1 type A
Resolution Frame rate*
Exposure
time
4104 x 2174 Full resolution 32 fps
27 µs - 15 s
2168 x 2168 Square 33fps
2052 x 1086 High speed 64 fps
2052 x 1086 High sensitivity 32 fps
3840 x 2160 4K 33 fps
1920 x 1080 Full HD 64 fps
* The maximum achievableframe rate is listed. The frame rate depends,
among other things, on the performance of the computer being used.
The frame rate corresponds to the maximum displayspeed of the
live-image (frame rate in frames/second (fps)).
2 The DP23 / DP28 camera
11
