4.2 Connecting the USB camera cable
ATTENTION
Use only the supplied USB camera cable
Operate the camera only with the supplied USB camera
cable. Only then will the functionality of the camera and
compliance with the EMC basic standards be ensured.
1. Connect the USB type C plug (a)to the camera’s USB type C
socket (b) and secure it with the two screws (c).
2. Connect the USB camera cable's USB type A plug (d) to the
USB 3.1 port (e)of the computer or the DP2-AOU.
Depending on the computer, the USB 3.1 port is either
colored blue or labeled "SS".
The camera can’t be operated using a USB 2.0 port.
DP23 / DP28
18
