2.4 Specifications
The DP23 / DP28 cameras are CMOS color cameras with a highframe
rate. They were specially developed to acquire images from light
microscopes. The cameras can be connected to allcommon types of
light microscopes by a C-mount adapter.
Specifications - DP23
Chip type C-mount CMOS camera
Chip size 1/1.8 Inch
Recording area
7.41 mm x 4.98 mm
8.92 mm diagonal
Maximum resolution
3088 x 2076 pixels
6.41 million pixels
Camera port of the microscope C-Mount
Input / output
On the camera:USB 3.1 type C (with
lock screws)
On the computer or DP2-AOU : USB
3.1 type A
Resolution Frame rate*
Exposure
time
3088 x 2076 Full resolution 45 fps
13 µs - 15 s
2072 x 2072 Square 59 fps
1544 x 1038 High speed 59 fps
1544 x 1038 High sensitivity 59 fps
1920 x 1080 Full HD 60fps
* The maximum achievableframe rate is listed. The frame rate depends,
among other things, on the performance of the computer being used.
DP23 / DP28
10
