4. RAM
If a RAM other than a PC2700 or greater, dual-channel RAM is used, the full-size live frame rate may drop.
5. Monitor
Us an Adobe RGB compatible monitor when using the camera head in the Adobe RGB mode.
Optimum color reproduction is not available if the sRGB/Adobe RGB setting of the camera head does not match the
setting of the monitor.
6. Sequential connection of PCIe units
Up to two PCIe units including the DP73 and a PCI interface board of the DP72/DP71/DP70/DP30BW or FV1000
(FV10-ASW-V1.5 or later) can be connected in series. Series connection of the FV300/FV500 is not possible.
However, their simultaneous operation is not available so it is required to select either PCI interface operation.
7. Power supply
The PCIe interface board should be powered by connecting the FDD power supply connector from the ATX power
supply in the PC.
If your PC does not have an available FDD power cable or the FDD power cable is too short, use the provided
HDD(4-pin) to FDD power conversion cable for the power supply.
And if your PC does not have an available HDD power cable (4-pin), use the provided SATA-to-HDD(4-pin) power
conversion adapter and HDD(4-pin)-to-FDD power conversion cable for the power supply.
