DP73
41
7 SPECIFICATIONS
DP73 Specifications
* These items can be set from the cellSens / OLYMPUS Stream.
** The values of these items are variable depending on the exposure time setting and the PC operating situations.
Item Specifications
Camera system Single-CCD color camera
Pixel shifting type
Image pickup device 1/1.8-inch color CCD
Total pixels: 2.1 million pixels
Effective pixels: 2.01 million pixels
Pixel pitch: 4.40 μm (H) x 4.40 μm (V)
Scanning method: progressive scanning
Cooling Peltier cooling
Natural air cooling
CCD temperature: room temperature - 10°C (max.)
Recorded image sizes 4800 x 3600 (pixel shifting, 3CCD mode*)
2400 x 1800 (pixel shifting, 3CCD mode*)
1600 x 1200 (1 x 1, 3CCD mode)*
800 x 600 (1 x 1)
800 x 600 (2 x 2)
* 3CCD mode is an application of the pixel shift function, which is the mode
to acquire the image with RGB color in every pixel.
Camera mount C-mount
