Olympus E-M5 User Manual

105 EN
Information
11
• Do not point the lens attached to the camera toward the sun. This may cause the camera
to malfunction or even ignite due to the magnifying effect of sunlight focusing through the
lens.
• Be careful not to lose the body cap and rear cap.
M.ZUIKO DIGITAL lens specifications
 Names of parts
1 Filter mount thread
2 Zoom ring (zoom lenses only)
3 Focus ring
4 Mount index
5 Electrical contacts
6 Front cap
7 Rear cap
If the hood is attached
to a lens with a
decorative ring, rotate
the ring to the left.
 Using power zoom lenses with macro functions
Lens operation is determined by the position of the zoom ring.
MACRO
+
Zoom ring
MACRO button
E-ZOOM (Power Zoom)
Rotate the zoom ring for power zoom. Zoom speed is
determined by the amount of rotation.
M-ZOOM (Manual Zoom) Rotate the zoom ring to zoom in and out.
MACRO (Macro Photography)
To photography subjects at a range of 0.2 to 0.5 m,
press the MACRO button and slide the zoom ring
forward. Zoom is not available.
• The role of the L-Fn button can be selected in the camera custom menu.
 Lens and camera combinations
Lens Camera Attachment AF Metering
Micro Four Thirds
system lens
Micro Four Thirds
system camera
Yes Yes Yes
Four Thirds system
lens
Attachment
possible with
mount adapter
Yes
*1
Yes
OM System lenses No Yes
*2
Micro Four Thirds
system lens
Four Thirds System
Camera
No No No
*1 [C-AF] and [C-AF+TR] of [AF Mode] cannot be used.
*2 Accurate metering not possible.

Olympus E-M5 Specifications

General

Megapixel	16.1 MP
Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	4/3 \
Image formats supported	JPG
Supported aspect ratios	3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	1024 x 768, 2560 x 1920, 4608 x 3456
Optical zoom	- x
Focal length range	- mm
Minimum aperture number	-
Focus adjustment	Auto/Manual
Auto Focus (AF) points	35
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash guide number	10 m
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVI, H.264, M-JPEG, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	610000 pixels
USB version	2.0
Product color	Black
Scene modes	Beach, Candlelight, Children, Close-up (macro), Documents, Fireworks, Night, Panorama, Portrait, Snow, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Auto, Flash, Fluorescent, Manual, Shade, Sunny, Tungsten, Underwater
Shooting modes	Auto, Manual, Movie, Program
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Camera file system	Exif 2.2
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, NOR, POL, POR, RUS, SER, SLK, SLV, SWE, TUR, UKR
Battery life (CIPA standard)	330 shots
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	41.9 mm
Width	121 mm
Height	89.6 mm
Weight	373 g
Weight (including battery)	425 g
