Olympus E-P3 User Manual

5 EN
Preparations for shooting
Basic guide
Attaching a lens to the camera
1
Remove the body cap from the camera and the rear cap from the lens.
1
2
1
2
2
Attach a lens to the camera.
# Cautions
Make sure the camera is turned off.
Do not press the lens release button.
Do not touch internal portions of the
camera.
•
•
•
Alignment
mark
Lens
attachment
mark
Align the lens attachment mark (red) on the camera
with the alignment mark (red) on the lens, then
insert the lens into the camera’s body.
Rotate the lens in the direction indicated by the
arrow until you hear it click.
•
•
3
Remove the lens cap.
2
1
1
Removing the lens from the camera
While pressing the lens release button, rotate the lens in
the direction of the arrow.
g “Interchangeable lenses” (P. 100)
2
1
Lens release button

Olympus E-P3 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Sensor Size	17.3 x 13.0 mm (Four Thirds)
Image Processor	TruePic VI
Screen Type	OLED touchscreen
Screen Resolution	610, 000 dots
Shutter Speed	60 - 1/4000 sec
Continuous Shooting	3 fps
Image Stabilization	Sensor-shift
Built-in Flash	Yes
Storage Media	SD/SDHC/SDXC
Dimensions	122 x 69 x 34 mm
Sensor Resolution	12.3 MP
ISO Sensitivity	ISO 200-12800
Autofocus Points	35
Screen Size	3.0 inch
Viewfinder	Optional external
Video Recording	1080i HD
Battery Type	BLS-5
Weight	369 g
