Olympus FL 36R - Turning on the Electronic Flash

11
EN
Turning on the electronic flash
Turn on the camera and electronic flash only after attaching to the
camera. After turning on the electronic flash, be sure to check the
remaining battery charge.
1 Press the POWER button.
 The control panel lights up and battery
charging starts.
 Press the POWER button again to turn the
electronic flash off.
2 Verify that the CHARGE lamp lights up.
 Replace the batteries if the time it takes for
the CHARGE lamp to light up exceeds the
following values.
Alkaline or oxyride batteries 30 sec. or more
NiMH or lithium batteries 10 sec. or more
 If the CHARGE lamp and AUTO CHECK
lamp blink simultaneously, it means that
the battery capacity is running low. In this
case, replace the batteries.
 Press the TEST button to test the flash
activation.
CHARGE lamp/
TEST button
POWER
button
AUTO CHECK lamp
Control panel
