Olympus FL 36R - Close-up Flash Setup

25
EN
Close-up flash
(0.5 - 1.0 m)
Close-up flash
When the distance to the subject is between 0.5 m (1.6 ft.) and 1.0 m
(3.3 ft.), the flash light emission area will not match the range included
in the shot. In this case, point the flash to the down-most angle (7°)
using the bounce lock release button.
1 Pressing the bounce lock release
button, tilt the light-emitting section to
the down-most angle (7°). The close-up
flash indicator lights in the control panel.
x
Notes
 The available shooting range is up to 2.5 m.
 The flash light may be blocked when the lens is long or large in diameter.
Be sure to perform test shooting.
 Do not use this function for any purpose other than close-up shooting. If
it is used in normal shooting, there will be insufficient illumination for the
upper half of the picture.
Available
shooting
range
