Olympus FL 36R - Names of Parts; Flash Unit Components; Checking the Package Contents

2
EN
Names of parts
Flash
Checking the package contents
The following items are included with the electronic
flash.
If anything is missing or damaged, contact the dealer
from whom you purchased the electronic flash.
Light-emitting area
Remote sensor
gP. 35
Lock ring gP. 9
AF illuminator light-emitting
area gP. 28, 34
 When the subject is dark
or low-contrast, the built-in
AF illuminator emits light to
facilitate focusing.
Wide panel
gP. 24
Auto light receptor gP. 16
Lock pin gP. 9
Electric contacts gP. 9
Electronic flash
