Preparation
1
15 EN
Charging and inserting the battery
1
Charging the battery.
Charging indicator
Charging in
progress
Lights orange
Charging
complete
Off
Charging error
Blinks orange
(Charging time: Up to
approximately 3 hours 30 minutes)
1
2
3
AC wall outlet
Lithium ion battery
Charging
indicator
AC cable
Direction indicating
mark (C)
Lithium ion
charger
• Unplug the charger when charging is complete.
2
Opening the battery/card
compartment cover.
1
2
Battery/card compartment lock
Battery/card compartment cover
3
Loading the battery.
• Use only BLS-50 batteries
(P. 14, 171).
Direction indicating mark
