3 Pre-observation/pre-operation preparation and inspection
Attaching the shoulder strap
The shoulder strap lets you attach the main unit to your body to do observations or to carry it
around easily from your shoulder.
Attach the main unit to your body
Hang the main unit from your shoulder
12 3
12 3
1 Attach the shoulder strap hooks to the two belt brackets and one of the two belt
holders.
2 Adjust the length of the shoulder strap by the length adjuster buckle, and ad-
just the screen to an easy-to-view angle.
3 Hang the shoulder strap on your shoulder and do observations.
1 Attach the shoulder strap hooks to the two belt brackets.
2 Adjust the length of the shoulder strap by the length adjuster buckle.
3 Hang the shoulder strap on your shoulder.
● Detaching the shoulder strap
To detach the shoulder strap, press the hook lever to remove
the hook from the main unit.
Hook lever
