148
Chapter 10 Specifications
Control unit Angulation Power assisted angulation.
Function of buttons ZOOM (T/W) lever
3-step zoom magnification switching
BRT (S/T) lever
<In the live screen>
Brightness changes in UP/DOWN format.
If the gain mode is “AUTO”, the WiDER changes accordingly. (LX only)
<BRT S lever in the thumbnail screen>
Selects multiple images to delete.
ANGLE joystick
Used to control the angulation.
MEAS/ENTER joystick
Used for menu selections and measurements.
MENU/EXIT button
Toggles the menu display on and off.
LIVE/GAIN button
Returns to the live screen from the menu screen.
Switches the gain mode in the live screen. (LX only)
FRZ/REC button
Freezing function and recording function done by one button.
Short push opens freeze screen.
Long push activates recording function.
VIEW button
Short push displays most recent image on retrieve screen.
Long push opens thumbnail screen.
ANGLE LOCK lever
Mechanically locks and maintains angulation.
Dimensions 311 (W) x 93 (D) x 192 (H) mm
(without insertion tube and cable)
Weight Approx. 750 g (without insertion tube and universal cable)
Total weight of all components IV8420L1/L2, IV8620L1/L2: 2.7 kg (with battery)
IV8435L1/L2, IV8635L1/L2: 2.9 kg (with battery)
IV88100L1/L2: 3.9 kg (including batteries)
