Chapter 2 Instrument nomenclature and functions
2.4 Optical adapter nomenclature and functions
 For 4-mm type
Stereo optical adapter
Objective lens
Illumination
Nut
Illumination
Objective lens
Product abbreviation
See “Optical adapter
specifications” (page
155).
Nut
Objective lens
First screw thread
Product abbreviation
See “Optical adapter
specifications” (page 155).
Electrode
O-ring
Second screw thread
Optical adapter positioning cut surface
Index
Index
Product name abbreviation and set
See “Optical adapter specifications”
(page 155).
Product name abbreviation and set
See “Optical adapter specifications”
(page 155).
