Chapter 3 Preparation and inspection before observation
3.5 Inspecting the control unit and the universal
cable
1 Check for irregularities such as damage or deformation to the
external material, buttons, joysticks, and levers.
2 Ensure that the universal cable is free of irregularities such as cuts
and buckling.
[BRT] lever
[ZOOM] lever
[FRZ/REC] button
(two located on the left
and right sides)
[ANGLE LOCK] lever
[ANGLE] joystick
Universal cable
[VIEW] button
[MEAS/ENTER] joystick
[LIVE/GAIN] button
[MENU/EXIT] button
