Chapter 3 Preparation and Inspection
31
LF-TP/DP/GP OPERATION MANUAL
1. Put a coin into the groove on the Lamp Holder and turn it counterclockwise.
Remove the Lamp Holder from the Main Body (see Figure 3.15).
Figure 3.15
2. Rotate the lamp clockwise and remove it from the Lamp Holder (see Figure
3.16).
Figure 3.16
3. Prepare a new lamp. Put the lamp into the Lamp Holder and rotate it
counterclockwise until it stops.
4. Wipe the surface of the lamp tip using a clean, lint-free cloth.
Electrical
Contact
Lamp
Lamp Holder
To Next Page
