SZ2 series
Stage plate mount hole
2
Installation
Friction surfaces
Stage plate
Use the one provided
with the base.
Gliding stage
Stage plate mount thread
Applicable base
Note 1. Be sure to clean the friction surfaces if dirt or
metallic power is attached on them.
Note 2. Do not place the gliding stage on the friction
surface directly on the desktop.
Note 3. Clean the friction surfaces periodically.
Hole the gliding stage by the edge and move it horizontally.
# The SZH-SC can be used only with reflected light illumination.
Finger hook
Stage plate
Specimen holder mount holes
(x 4)
Tube
Cup stage
Tilting limit angle: 30°
Specimen holder
Seat
Same size as the stage plate.
Seat
3
Operation
8-5 Cup Stage SZH-SC
1
External View and Nomenclature
