SZX2-ILLT
2
Safety Symbols
The following symbols are found on the equipment. Study the meaning of the symbols and always use the equipment in
the safest possible manner.
Symbol Explanation
Before use, carefully read the instruction manual. Improper use could result in personal injury to
the user and/or damage to the equipment.
Stands for oblique brightfield observation.
Indicates that the main switch is ON.
Indicates that the main switch is OFF.
1
Getting Ready
1. The LED transmitted light illuminator stand is a precision instrument. Handle it with care and avoid subjecting it to sudden
or severe impact.
2. Do not use the equipment where it is subjected to direct sunlight, high temperature and humidity, or vibration. (For the
operating environment, see Chapter 3, “SPECIFICATIONS” on page 8.)
3. The LED transmitted light illuminator stand can be used with the following microscope bodies.
· SZX2 series.
4. Install the LED transmitted light illuminator stand on a desktop surface that is as level as less than 5° from the horizontal
plane, and the mounted load should be less than 7 kilograms.
5. This equipment is not provided with the ESD (Electro Static Discharge) compatibility.
6. Light intensity does not change linearly with respect to the rotation of the light intensity control dial.
7. The color tone varies depending on the individual characteristics of the LED.
8. Do not apply an excessive force beyond the stopper mechanism of each control. Otherwise, the control may be damaged.
2
Maintenance and Storage
1. To clean the lenses and other glass components, simply blow dirty away using a commercially available blower and wipe
gently using a piece of cleaning paper (or clean gauze).
If a lens is stained with fingerprints or oil smudges, wipe it gauze slightly moistened with commercially available absolute
alcohol.
Since the absolute alcohol is highly flammable, it must be handled carefully.
Be sure to keep it away from open flames or potential sources of electrical sparks -- for example, electrical
equipment that is being switched on or off.
Also remember to always use it only in a well-ventilated room.
2. Do not use organic solvents to clean non-optical components. If smudges are difficult to clean, wipe them with a soft
cloth slightly moistened with a diluted neutral detergent.
3. The stage surface is provided with a simplified waterproof construction. If water is spilt on it, promptly set the main switch
to “ ” (OFF), unplug the power cord and wipe with a dry cloth. Also remove the stage glass and wipe the window lens
and the surroundings with a piece of soft gauze, etc.
If water penetrates inside the equipment, contact Olympus to have the electrical safety checked.
4. Do not disassemble any part of the equipment as this could result in malfunction or reduced performance.
