Olympus U-RFLT50 - Reflected Light Fluorescent Mirror Selection; Selecting Fluorescent Mirrors for Excitation

10
REFLECTED FLUORESCENCE SYSTEM FOR CKX41
2
Selecting the Reflected Light Fluorescent Mirror
}The reflected light fluorescent mirrors for B-excitation and G-excitation have been installed in the
fluorescent mirror slider at the factory.
If required, the optional CKX-NU mirror for U-excitation can be mounted in the open position or by
removing the B- or G-excitation mirror. (Work to be done by the dealer)
Fluorescent mirror specifications
Excitation Fluorescent Mirror Dichroic Mirror Excitation Filter Barrier Filter Applications
BDM500BP460-490CBA520 IF
·FITC: Fluorescent antibody method
·Acidine orange: DNA, RNA
·Auramine: Tubercle bacillus
·EGFP, S65T, RSGFP
GDM570BP480-550CBA590
·Rhodamine, TRITC: Fluorescent anti-
body method
·Propidium iodide: DNA
·RFP
UCKX-NU DM400BP360-370BA420
·Auto-fluorescence observation
·DAPI: DNA
·Hoechest 33258, 33342: Chromosome
Spectral characteristics
B-excitation
Transmittance %
Wavelength nm
G-excitation
Transmittance %
Wavelength nm
U-excitation
Wavelength nm
Transmittance %
