6
Hand Switch U-HSTR2
}The button functions shown below refer to those in the standalone operation.
The button functions can be set arbitrarily when PC control (remote control) is used.
For other operating instructions, refer to the BX-UCB/U-HSTR2 instruction manual.
DF (Darkfield) button
Focus Adjustment Knob Interface U-IFFH
U-FH connector
Power Supply Unit TH4
}For details, refer to the separate
instruction manual.
Main switch
BF (Brightfield) button
AS+ (Aperture iris diaphragm open)
button
AS– (Aperture iris diaphragm close)
button
Projections for blind-touch operation
Connector
Objective buttons
UCB1 (illuminator) connector
BX-UCB connector
I : ON. : OFF.
Light intensity control
POWER LED
REMOTE LED
To Next Page
