21
BXFMA
*Equipped with the glass thickness compensation ring.
Objectives for LCD Panel
Optical
characteristics
Magnifi-
cation
N.A.
W.D.
(mm)
Cover
glass
thick
ness
(mm)
Resolu-
tion
(μm)
Eyepieces
Series
WHN10X (FN22)
SWH10X (FN26.5)
Total
mag.
Depth
of focus
(μm)
Field
of view
(mm)
Total
mag.
Depth
of focus
(μm)
Field
of view
(mm)
Marking
UIS2
series
LCPLFLN
Long-WD Plan
Semi-Apochromat
(FN26.5)
LCPlanFLN*
20XLCD 0.45 7.4-8.3 0-1.2 0.75 200X 5.2 1.1 200X 5.2 1.33
50XLCD 0.70 2.2-3 0-1.2 0.48 500X 1.6 0.44 500X 1.6 0.53
100XLCD 0.85 0.9-1.2 0-0.7 0.39 1000X 0.79 0.22 1000X 0.79 0.27
Optical
characteristics
MPLAPON Plan
Apochromat
50X 0.95 0.35 0 0.35 500X 0.7 0.44 500X 0.7 0.53
100X 0.95 0.35 0 0.35 1000X 0.4 0.22 1000X 0.4 0.27
MPlanApoN
UIS2
series
Magnifi-
cation
N.A.
W.D.
(mm)
Cover
glass
thick
ness
(mm)
Resolu-
tion
(μm)
Eyepieces
Series
WHN10X (FN22)
SWH10X (FN26.5)
Total
mag.
Depth
of focus
(μm)
Field
of view
(mm)
Total
mag.
Depth
of focus
(μm)
Field
of view
(mm)
Marking
