EN 13
EN
• Instruction manual (this manual)
1
5
6
7
3
2
4
1 button
• The target light turns on when press
this button. The target light turns off
when press this button again.
• The target light turns off when the
flash emits, and lights up again when
the flash is ready to emit (when the
Ready lamp turns in red).
2 Battery cap lock
3 Battery cap
4 Light level dial
5 Mode dial
6 Ready/TTL lamp
• Turns in red when the flash is ready.
• Turns in green for approx. 2 seconds
after emitting with TTL flash output.
7 Strap eyelet
Silicone grease O-ring remover
Arm mount knob
Diffuser
Diffuser strap
