45) Ensure that the EDIT option is selected; otherwise, turn the knob to select it, then press to
confirm.
46) The hour will be indicated after Time. Turn the knob and adjust the current hour, then
press the knob to confirm.
47) The minute will be indicated. Turn the knob to adjust the current minute, then press to
confirm.
48) The second will be indicated. Turn the knob to adjust the current second, then press to
confirm.
49) The day of the month will be indicated after Date. Turn the knob to set the current day,
then press to confirm.
50) The month will be indicated. Turn the knob to set the current month, then press to
confirm.
51) The year will be indicated. Turn the knob to set the current year, then press to confirm.
52) OK will be highlighted. Three choices are now available:
- If the parameters set are correct – skip directly to step 53) to confirm the settings.
- If the parameters set are all incorrect – cancel all settings by turning the knob until ABORT is
highlighted, then skip to step 53).
- If a slight adjustment to the parameters is required – turn the knob until EDIT is highlighted,
then return to step 46).
53) Press the knob to confirm. You will return to the SETUP menu screen indicated in step 42).
2.2.8 Changing from stand-by to full operation
The transmitter is thus programmed with the basic parameters. You can now return to the
default screen by pressing the ESCAPE button. Of course, you may now need to adjust other
parameters, according to your requirements (e.g., modulation of the auxiliary RDS/SCA signal.
Once you are sure that you’ve correctly programmed all the parameters, you can place the
transceiver in full operation by pressing the ON/STAND-BY button. Ensure that the ON LED is
lit up in green.
If the red ALARM indicator light appears, this means that an alarm event has occurred.
When this happens, check the type of alarm on the display, refer to the error table, and
solve the problem.
2.2.9 Checking parameters
We recommend that all the operating parameters be verified the first time that the
transceiver is placed in full operation, via the VIEW menu. To access this menu from the
default screen:
