Section 1 - Introduction
The low cost OS101 mini-infrared transmitter provides non-contact
temperature measurement for industrial applications. The unit measures a
temperature range of -18 to 538°C (0-1000°F) and provides a linear analog
output of either 4-20 mA, 0-5 VDC, K type TC, 1 mV/°C, or 1 mV/°F.
The new OS102 mini-infrared transmitter has all the functions of OS101
plus a built-in LED display that shows the measured temperature in
degrees F or degrees C which is switchable in the field.
The miniature sensor head design 2.5 cm dia. x 6.3 cm Length (1" x 2.5") is
ideal for measuring temperature in confined, and hard to reach places.
The aluminum sensor head as well as the rugged electronic housing (Die
cast Aluminum) are NEMA-4 rated.
The sensor head is connected to the electronic housing via a 1.82 m (6 feet)
shielded cable as standard. The unit provides field adjustable alarm
output.
Section 2 - Installation
2.1 Unpacking
Remove the packing list and verify that you have received all your
equipment. If you have any questions about the shipment, please call
Customer Service at:
1-800-622-2378 or 203-359-1660. We can also be reached on the internet:
omega.com e-mail: info@omega.com
When you receive the shipment, inspect the container and equipment for
any signs of damage. Note any evidence of rough handling in transit.
Immediately report any damage to the shipping agent.
The carrier will not honor any damage claims unless all the shipping materials are saved for
inspection. After examination and removing contents, save packing material and carton in the
event reshipment is necessary.
The following items are supplied in the box:
• The infrared transmitter including the sensor head and the 1.82 m
(6 feet) shielded cable
• User's Manual
• Mounting Nut
OS100 Series - Introduction
1
1-1
NOTE:
