Current amplifier CMA 56
24
4 Connections and Interfaces
4.1 Connectors on the
Front Panel
The output sockets are situated on the front panel; three current phases and a
neutral. In addition the LED indicators to display the operating states of the
amplifiers and the ON/OFF power switch are here.
Figure 3 Front view CMA 56
