Current amplifier CMA 56
42
Figure 16 Output power curve at 50/60Hz for single phase operation with
parallel connection (1+2+3)
 Methods for increasing the output power are found in Chapter 5 "Increasing
the Output Power".
7.3 Inputs "Ampl. in"
3 analog inputs
Input resistance
> 40k
Input voltage range
0 ... 5V
Amplification
10A / 1V (1V at input  10A at
output)
max. permissible input voltage
15V
peak
Isolation input  output
SELV (SaveExtraLowVoltage)
Table 10 Inputs
