Omicron CMA 56 - Rear Panel Interfaces

Current amplifier CMA 56
28
4.2 Rear View
The mains connection (power supply block) and the connection to the
CMC test device (detail b) are located on the rear panel.
Figure 6 Rear view CMA 56
4.2.1 Mains Fuse
Attention: disconnect the mains cable of the device before replacing the mains
fuse!
Fuse: T10AH 250V.
