Omicron CMA 56 - Single Phase Parallel Operation

Increasing the Output Power
37
5.3 Single Phase Operation
Parallel Connection 1+2+3
Maximum output voltage: 10V
rms
Maximum power: 420VA at 45A
Current range: 1  0 … 150A
rms
The currents 1, 2 and 3 will be connected in parallel and brought together at
the load (burden).
All current channels must be controlled in phase so that the currents will add
up.
1'
1'
N'
N'
1 2 3 N
1'
N'
1
3
2
N'
N
N
N
I
1
I
2
I
3
I’
Figure 13 Single phase operation;
parallel connection 1+2+3
See also the power curve in Figure 16.
