Omicron CMA 56 - Page 46

Current amplifier CMA 56
46
CMC 156
Amplifier
(CMA, CMS)
Ampl. in
ext. Interf.
Ampl. out
Gen. out. 7-12
Ampl. in
Connection cable
CMC 156 amplifier
6mm connector
Branching plug
Plug for socket
"Ampl. in"
Connection cable
CMC 156 amplifier
Plug for socket
"Ampl. out"
CMA 56
Figure 17 Connection cables and plugs
