GPS Synchronization Unit CMGPS
18
Synchronization pulse
Other LED conditions as those described above indicate faults and are outlined
in section 7 ”Faults, Possible Causes, Remedies” on page 41.
On
Pu l s e
Sea r c h i n g
Locked
LED "ON" is lit.
LED "Searching/Locked" is lit.
LED "Pulse" is lit for approx. 500 ms during the
output of the synchronization pulse at the outputs
Pulse out 1 and/or Pulse out 2.
