Omicron CMGPS - Power Supply Specifications; Antenna Specifications

GPS Synchronization Unit CMGPS
36
6.3 Power Supply
Table 6-3:
Power supply
6.4 Antenna
Table 6-4:
Antenna
Power supply unit
Supply voltage
Power supply unit
Rated current input
Frequency
• nominal freq.:
• admissible range:
100 - 240 V
AC
400 mA
50/60 Hz
47 - 63 Hz
Output voltage
Rated current output
18 V
DC
840 mA
Power supply CMGPS
Nominal supply voltage
CMGPS
18 V
DC
/ 150 mA
Admissible range of power
supply voltage
+8 V
DC
... +30 V
DC
Power consumption 2.5 W
Connection Reverse polarity protected
Protection class II
Antenna
Antenna Active
Connection of device Coaxial (SMA socket)
Connection of antenna Screw-on type (SMA plug)
Antenna extension cable
RG58 50
Ω coaxial cable, 15 m (45 ft.)
(approx. 1 dB/m or 0.3 dB/ft)
1
1. There is an optional extension set of 2 x 20 m (2 x 60 ft.) with SMA adapters available for a total
extension of 40 m (120 ft.); refer to Table 8-1: ”Ordering information for the CMGPS
synchronization (set)” on page 43.
