23
Construction and Functioning
3.3.5 Block Diagram of the CMGPS
Figure 3-12:
Block diagram of
the CMGPS
18 V
DC
from
power supply unit
ext. Interf.
Pulse
out 1
DC input
PWR
DC/DC
Pulse out 2
(VDE884)
Housing (metal)Gnd
GPS receiver
Interface modul
(pulse preparation)
Antenna
input
+5V
Y1
