Omicron CT Analyzer User Manual

Getting Started with CT Analyzer & CT SB2
22 OMICRON
4.6 Compact Flash card interface
4.7 Remote control interface
The remote control interface of the CT Analyzer is exclusively intended to connect the CT Analyzer to a
computer (e.g. running the CT Analyzer PC Toolset software) or to the optional CT SB2 switch box (for
multi-ratio CT measurement).
As of serial number JHxxxx or newer, the CT Analyzer is equipped with a USB interface and a RS232
interface.
Note: The user has to select the interface to be used in the CT Analyzer settings before connecting the
CT Analyzer to a computer. The CT Analyzer will only communicate via the selected interface. It will not
be recognized by the computer if the CT Analyzer settings do not match the interface used for
connection.
Table 4-7: Ratio measurement accuracy for 5 A CTs at rated current
CT ratio I
sn
Rated power
1
1. Nominal burden of the CT.
Typical accuracy Guaranteed
accuracy
0.2 - 1 5 1.0 - 75VA 0.05% 0.1%
> 1 - 2000 5 0 - 75VA 0.02% 0.05%
> 2000 - 5000 5 0 - 75VA 0.03% 0.1%
> 5000 - 10000 5 0 - 75VA 0.05% 0.2%
Table 4-8: Phase measurement accuracy at rated current
Characteristic Rating
Resolution 0.01min
Accuracy (cos
ϕ 0.8 - 1)
1min (typical)
3min (guaranteed)
Table 4-9: Turns ratio measurement accuracy
Characteristic Rating
Resolution 0.01 turns
Accuracy 0.05% (typical)
0.1% (guaranteed)
Table 4-10: Compact Flash card interface
Characteristic Rating
Card type CF type 1
Allowed memory size 16MB - 2GB

Omicron CT Analyzer Specifications

General

Type	CT Analyzer
Measurement Categories	CAT III 300 V
Power Supply	100-240 V AC, 50/60 Hz
Primary Application	Testing and calibrating current transformers
Interface	USB, Ethernet
Standards	IEC 60044-1
Voltage Range	0 to 300 V
Accuracy	±0.02%
Basic Accuracy	0.02% (typical)
